China Youngman Squash is WSF All-Glass Squash Court Supplier. We build squash courts systems and do installation for customers. Squash is a very popular sport. At present, more and more investment is being made in Squash Courts in China. Both the plastering and formwork constructions need to be built on the basis of civil engineering walls. The full glass installation process is completely different. The steel frame structure and special safety tempered glass are characterized by outstanding visual effects and are suitable for watching games. At the same time, the cost is slightly higher.

Squash court construction standards

In order to meet the standards for the use of squash courts and reduce errors during construction, when building walls, the following details need to be noted: the exact size of the squash court, the standard size of the wall is 6412 to 6416MM, and then 6-8MM thicker than each wall. In addition, the allowable error length and width of each wall after construction are 1MM and 1.5MM respectively. The squash court consists of a wall system, a floor system, a glass back wall system, a lighting system (built by the hall), and a ventilation system (built by the hall). The last two systems can also be designed and installed by Party A.

The standard venues specified by the International Squash Federation are divided into singles and doubles. The singles court is 9.75 meters long, 6.4 meters wide and 4.57 meters high; the doubles court is 13.72 meters long, 7.62 meters wide and 6.1 meters high. The squash court in the United States is smaller, with a width of only 5.64 meters and a height of 4.88 meters.

1. Squash court dimensions:

Singles: 6.4m wide, 9.75m long, 4.57m high in front, Double Court Size:7.62m wide, 9.75m long, 6.1m high, 2.13m high in back, 5-6m high in top floor, 0.48m high in castanets

2. Technical standards

Wall system: 12mm special safety tempered glass

Wood floor system: 22mm thick maple sports floor

Glass back wall system: 12mm thick tempered glass and hardware accessories

3. Squash court product portfolio

(I) Wall system

Material properties:

1. Special 12mm tempered glass is used to connect with hardware, combining safety and beauty. It is important to be able to install and disassemble quickly.

2. In order to improve the rebound effect of the ball, the largest specification raw materials are used as much as possible for each plate of the wall glass. This design can achieve an average rebound force for each point of the wall, and the sport can be fully utilized in the game.

3. The cost is slightly higher, but the performance is good, the ornamental effect is good, and it is suitable for competition venues.

(II) Wood Floor system

Material performance:

1. Good rebound performance against the ball;

2. Shock absorption and earthquake resistance;

3. Good sound insulation;

4. The unique elastic cushion provides unique elasticity and withstands heavy pressure for the hard maple floor, reducing the chance of athletes being injured by bouncing on the floor.

5. The squash floor is designed according to the standards of the World Squash Federation (WSF). The floor surface can absorb sweat and is easy to maintain.

(III) Glass back wall system product performance:

1. High-strength hardware accessories:

The aluminum parts specially customized by professional factories are more than 20% stronger than other aluminum accessories, and the surface hardness reaches 16hw. And it has beautiful appearance, strong fatigue resistance, and is easy to install.

2. Good safety performance:

Safety performance is the focus that is more likely to be paid attention to. Each component of the system has been repeatedly tested for safety and can withstand strong impacts and overloads. If the door panel or side support plate breaks accidentally, the glass will be shattered into small and blunt fragments, which will not cause harm to the human body. 1. High-strength hardware accessories: Cast aluminum accessories are more than 20% stronger than other plastic accessories.
